Double Glass Component Glass
The double glass module cover plate commonly uses 2.0mm or 2.5mm ultra white embossed solar tempered coated glass (our company can make the thinnest glass 1.6mm). The thinner the cover glass, the higher its transmittance, thereby improving the output power of the entire module. The back panel uses ordinary float glass with a thickness of 2.0mm-6.0mm instead of TPT back panel. The glass back panel can be punched or not punched according to customer needs. No aluminum frame is required, which has a significant cost advantage over traditional components.
Keywords:
Double Glass Component Glass
Category：
Product Description
The double glass module cover plate commonly uses 2.0mm or 2.5mm ultra white embossed solar tempered coated glass (our company can make the thinnest glass 1.6mm). The thinner the cover glass, the higher its transmittance, thereby improving the output power of the entire module.
The back panel uses ordinary float glass with a thickness of 2.0mm-6.0mm instead of TPT back panel. The glass back panel can be punched or not punched according to customer needs. No aluminum frame is required, which has a significant cost advantage over traditional components.
|
Product thickness |
2.0mm-6.0mm |
|
Conventional thickness |
2.0mm、2.5mm、2.8mm、3.2mm、4.0mm、5.0mm |
|
Maximum glass size |
1050*2100mm |
|
Aperture |
20-50mm |
|
Hole position |
The distance between the hole and the edge of the glass shall not be less than 10mm |
